<% Title = "Panasonic Toughbook H2 - Panasonic Toughbook H2 Rugged Tablet PC" Description = "The Panasonic Toughbook H2 rugged tablet pc is a lightweight, durable and a rugged tablet pc with a rugged touch screen, ideal for a variety of industries, including healthcare, transportation, utilities, veterans affairs, and more" Keywords = "toughbook h2, h2, tablet pc, toughbook tablet pc, handheld computer, cf-h2, toughbook cf-h2, panasonic cf-h2, h2 handheld pc, rugged tablet, fully rugged tablet" Header = "bg-header-tablet.jpg" BreadCrumbStr = "100#1#35#123" BreadCrumbCount = 4 %> <% GetProductHTMLTop "topitem_Products", "dropMenu_Products", "dropMenu_Products_Rugged_Tablets_PCs", "", "", "Rugged_Tablets_PC", "Toughbook_H2", "" GenerateBreadCrumb BreadCrumbStr, BreadCrumbCount GenerateProductFeatures "Intel® Core™ i5 vPro™ Processor#Sealed Fanless All-weather Design#Sunlight-viewable Up to 6000 Nit in Direct Sunlight#USB, Serial and Ethernet Ports#Long-life Hot-swappable Twin Batteries Provide Limitless Hours of Use#Available Built-in Camera, RFID, SmartCard and Barcode Readers#Choice of 3G Gobi™ or 4G LTE Mobile Broadband", "Toughbook CF-H2.pdf", Title, "dropMenu_Products", "dropMenu_Products_Rugged_Tablets_PCs", "Rugged_Tablets_PC", "Toughbook_H2" GenerateContentHeadline "Toughbook H2", "Fully-Rugged Tablet" GeneratePictureSlider2 "toughbook_h2/H2_Head_On.jpg#toughbook_h2/H2_Head_On_Dramatic_Angle.jpg#toughbook_h2/H2_Right.jpg#toughbook_h2/H2_Back.jpg", "" GenerateProductMenu("") OpenProductInformationbox() GenerateOverviewText "The new rugged Panasonic Toughbook^®H2 handheld tablet PC runs a full OS (Windows^® 7 Professional) and is the ultimate productivity tool for mobile workers. With superior ergonomics, a brilliant 10.1"" sunlight-viewable LED screen capable of up to 6000 nit in direct sun and sealed all-weather design, the H2 lets you work virtually anywhere. Designed with a fast Intel^® Core^™i5 vPro^™ processor, magnesium alloy chassis encased in polycarbonate, the IP65 and MIL-STD-810G certified Toughbook H2 delivers a complete range of embedded wireless features including Wi-Fi, Bluetooth^® and optional 4G LTE (Fall 2011) or Gobi^™2000 3G mobile broadband. Add to that hot-swappable twin batteries for maximum uptime, ports such as USB, serial and ethernet, optional integrated barcode and SmartCard readers, and youve got a handheld tablet PC that is unmatched in the field.", "", "2nd generation Intel® Core™ i5 vPro™ processor.
Intel, the Intel logo, Intel Core, Intel vPro, Core Inside and vPro Inside are trademarks of Intel Corporation in the U.S. and/or other countries." GenerateSpecificationText "Durability#Software#CPU#Storage & Memory#Display#Audio#Keyboard & Input#Interface#Wireless#Power Supply#Power Management#Security Features#Integrated Features#Warranty#Dimensions & Weight#Safety Certifications#Integrated Options₁₀#Accessoires₁₀", "MIL-STD-810G certified (6' drop, shock, vibration, rain, dust, sand, altitude, freeze/thaw, high/low temperature, temperature shock, humidity, explosive atmosphere)₁
IP65 certified1 sealed all-weather design
Hard drive heater
Magnesium alloy chassis encased with polycarbonate
Shock-mounted flex-connect hard drive
Integrated handle and ergonomic rubber hand strap
Reinforced locking port covers#Genuine Windows® 7 Professional 32-bit₂ or Genuine Windows® 7 Professional 64-bit₂
Panasonic Utilities (including Dashboard and Cleaning Reminder Tool), Recovery Partition#Intel® Core™ i5-2557M vPro™ Processor
– 1.7GHz with Turbo Boost up to 2.7GHz
– Intel® Smart Cache 3MB#4GB SDRAM (DDR3-1333MHz), expandable to 8GB3,₄
n 320GB 7200rpm hard drive (shock-mounted and flex-connect)₄
– Optional 128GB reinforced flex-connect SSD₄#10.1"" XGA sunlight-viewable LED 1024 x 768 dual touch
– TransflectivePlus and Panasonic CircuLumin™ technology
– 1-6000 nit (depending on lighting conditions and settings)₅
– Anti-reflective, anti-glare screen treatments and circular polarizer
– Ambient light sensor
Intel® QM67 video controller, max 1563MB shared VRAM with 32-bit₆
External video support up to 1280 x 1024 at 16.7 million colors
Concealed mode#Intel® high-definition audio compliant
Integrated speaker#Dual touch LCD (touchscreen and digitizer)
Integrated stylus holder
74-key on-screen keyboard with dedicated Windows® key
Up to 5 user-defined programmable buttons (varies by model)#Docking connector - Dedicated 19-pin
Serial - D-sub 9-pin
USB 2.0 (opt. 2nd usb port)₇ - 4-pin
10/100/1000 Ethernet - RJ-45#Optional integrated LTE 4G mobile broadband (Fall 2011)
Optional integrated Gobi™2000 3G mobile broadband
Intel® Centrino® Advanced-N 6205 802.11a/b/g/n
Bluetooth® v2.1 + EDR (Class 1)
Security
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES#Twin hot-swappable Li-Ion battery packs
– 7.2V, typical 3400mAh, minimum 3200mAh each battery
Battery operation: 6.5 hours (with both batteries)₈
Battery charging time: 3 hours on₈
AC Adapter: AC 100V-240V 50/60Hz, auto sensing/switching worldwide power supply#Suspend/Resume Function, Hibernation, Standby, ACPI BIOS#Password Security: Supervisor, User, Hard Disk Lock
Kensington cable lock slot (on optional cradle)
Trusted platform module (TPM) security chip v.1.2
Computrace® theft protection agent in BIOS₉
Intel® Anti-Theft Technology
Fingerprint reader
Insertable SmartCard reader
Contactless SmartCard reader#H2 LITE
Base model
H2 PRO
2.0MP camera with auto focus and LED light
Barcode reader
H2 ELITE
2.0MP camera with auto focus and LED light
Barcode reader
Insertable SmartCard reader
13.56MHz Contactless RFID and SmartCard reader
– ISO 15693 and 14443 A/B compliant
Fingerprint reader#3-year limited warranty, parts and labor#10.8""(L) x 10.6""(W) x 2.3""(H)
3.5 lbs. (with handle, strap and both batteries)#IT Equipment Safety (EN:EU, UL:US) - EN/IEC 60950-1 UL 60950-1

Medical Electrical Equipment Safety (EU) - EN/IEC 60601-1 (with battery operation)
Medical Electrical Equipment Safety (Canada) - CAN/CSA-C22.2 No.601.1-M90
IT Equipment EMI (US) - FCC CFR 47 P.15 Sub B-Class B
IT Equipment EMI (EU) - EN 55022/CISPR 22-Class B
IT Equipment EMS (EU) - EN 55024
Industrial EMI (EU) - EN 55011/CISPR 11-Class B
Radio (US) - FCC CFR 47 P.15 Sub C
Radio (Canada) - RSS-210
SAR (US) - FCC CFR 47 P.2#LTE 4G mobile broadband (Fall 2011)
Gobi™2000 3G mobile broadband (EV-DO Rev. A, HSPA)
GPS receiver
2nd USB port (replaces Ethernet port)
128GB solid state drive (SSD)#AC Adapter (3-prong) - CF-AA6373AM
Lithium Ion Battery Pack11 - CF-VZSU53W
4-Bay Battery Charger - CF-VCBU11U
LIND Car Adapter 120W - CF-LNDDC120
LIND Car Adapter 120W Mounting Bracket - CF-LNDBRK120
LIND Car/AC Adapter 90W (with USB port) - CF-LNDACDC90
LIND Car Adapter 90W MIL-STD - CF-LNDMLDC90
LIND Car Adapter 80W - CF-LNDDC80
LIND Shutdown Timer - CF-LNDLPT
InfoCase H2 Shoulder Strap - TBCH1SS-BLK-P
InfoCase H2 Inversion Strap - TBCH1SSINV-P
InfoCase H2 Always-on Sleeve - TBCH2SLVE-P
InfoCase U1/H2 Battery Pouch - TBCU1BPCH-P
Desktop Cradle/Spare 2-Bay Battery Charger - CF-VEBH21KU
Memory Card 4GB DDR3 - CF-WMBA1004G
Magnetic Micro-dock (USB x2, LAN) - CF-VEBH12U
Gamber-Johnson Wall/Cart Mount - TBD
Gamber-Johnson Wall/Cart Mount (no electronics) - TBD
Gamber-Johnson Vehicle Dock (no pass-through) - 7160-0348
Gamber-Johnson Vehicle Dock (no electronics) - 7160-0349
Replacement Stylus - CF-VNP011U
Tether - CF-VNT003U
10.1"" LCD Protector Film - CF-VPF13AU", "Please consult your reseller or Panasonic representative before purchasing.
₁ Tested by a national independent third party lab following MIL-STD-810G Method 516.6 Procedure IV for transit drop test and IEC 60529 Sections 13.4, 13.6.2, 14.2.5 and 14.3 for IP65. Stylus has passed IP65 testing but has not been certified.
₂A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
₃Total usable memory will be less depending upon actual system configuration.
₄1GB = 1,000,000,000 bytes.
₅ 500 nit without ambient light assistance. Up to 6000 nit in clear, sunny conditions under direct sunlight.
₆ The size of the VRAM cannot be set by the user and varies by operating system as well as size of RAM. Windows 7 64-bit max. VRAM is 1696MB with 4GB of memory.
₇Replaces Ethernet port.
₈ Battery performance features such as charge time and life span can vary according to the conditions under which the computer and battery are used. Battery operation and recharge times will vary based on many factors, including screen brightness, applications, features, power management, battery conditioning and other customer preferences. Battery testing results from MobileMark 2007.
₉Requires software and activation to enable theft protection.
₁₀ Accessories and Integrated Options may vary depending on your configuration.
₁₁7.2V, 2900mAh." GenerateOptionalAccessoires "toughbook_h2/optional_accessoires/cf-aa6373am.jpg#toughbook_h2/optional_accessoires/cf-lndacdc90.jpg#toughbook_h2/optional_accessoires/cf-lndbrk120.jpg#toughbook_h2/optional_accessoires/cf-lnddc120.jpg#toughbook_h2/optional_accessoires/cf-lnddc80.jpg#toughbook_h2/optional_accessoires/cf-lndlpt.jpg#toughbook_h2/optional_accessoires/cf-lndmldc90.jpg#toughbook_h2/optional_accessoires/cf-vcbu11u.jpg#toughbook_h2/optional_accessoires/cf-vebh12u.jpg#toughbook_h2/optional_accessoires/cf-vnp011u.jpg#toughbook_h2/optional_accessoires/cf-vnt003u.jpg#toughbook_h2/optional_accessoires/cf-vpf13au.jpg#toughbook_h2/optional_accessoires/cf-vzsu53w.jpg", "AC Adapter (3-prong)#LIND Car/AC Adapter 90W (with USB port)#LIND Car Adapter 120W Mounting Bracket#LIND Car Adapter 120W#LIND Car Adapter 80W#LIND Shutdown Timer#LIND Car Adapter 90W MIL-STD#4-bay Battery Charger#Magnetic Micro-dock USB (2), RJ-45 #Dual Touch Replacement Stylus (for Digitizer)#Tether#10.1"" LCD Protector Film for Dual Touch #Lithium Ion Battery Pack" GenerateVideos "", "" CloseProductInformationbox() GetHTMLButton() %>
